STEREOLITHOGRAPHY (SLA)

How does SLA 3D Printing work?



Stereolithography (SLA) is a 3D printing process that utilizes a liquid resin as the printing material.  The model is sliced into thin layers. In SLA, a vat of liquid resin is used, and a build platform is submerged into the resin. A laser or a light source then selectively cures the resin, solidifying it layer by layer based on the sliced design. As each layer is cured, the build platform gradually lifts out of the vat, and the excess liquid resin is drained away. Finally, the object is fully cured and removed from the build platform.



SLA offers high precision and smooth surface finish, making it ideal for producing intricate and detailed parts, jewelry, dental models, and other highly accurate prototypes.

Use Print My Part’s SLA 3D Printing Service to get your parts printed!



Stereolithography Capabilities

Maximum Part Size Tolerances Layer Height Minimum Feature Size Standard Lead Time
Form Labs Form 3B+
145 x 145 x 145mm (5.7 x 5.7 x 6.8in)
± 0.5% with a lower limit: ± 0.2 mm (0.007 in)
25-100 microns
0.2mm
From 2 Business Days
Formlabs Form 3L
335 × 200 × 320 mm (13.2 × 7.9 × 12.6 in)
± 0.5% with a lower limit: ± 0.2 mm (0.007 in)
50-100 microns
0.2mm
From 5 Business Days

SLA 3D Printing Material Selection

brake-caliper-nav

Standard Resins

Standard Resins offer a high detail way to prototype your parts. There are 4 different colors to chose from: grey, white, black and clear.

IMG_7135

Speciality Resins

Need a special property in your parts? Print my Parts offers numerous different specialty resins such as, Elastic Resin, Tough Resin, and Castable Wax Resin.

Pros and Cons of Choosing SLA

rs-f2-to20-01_01_03_2x

Pros

Jaw,Models,Being,Printed,In,Resin,On,A,3d,Printer

Cons

SLA Quality Standards

Standard Processing includes, removal, sanding of support marks, finally parts are washed and cured to resin manufacturer’s standard procedures.

Custom Finishing: Sanding, Priming, Painting, Threading, Inserts

More Finishing Options on request!

Type of Feature Recommended Minimum
Minimum Feature size
0.2mm (0.000787in)
Minimum Hole Diameter
0.5mm (0.0197in)
Minimum Wall Size
1.0mm (0.0393in)
Drain Hole Diameter
4mm (0.157 in)

Designing for SLA

Different minimums for designing for SLA 3D Printed parts. Try to minimize unneeded overhangs to reduce support material needed.
